Radiolink R16SM

16 Channels Receiver

Real-time Built-In Telemetry

Cutting-edge Communication Technology

3000 Meters Control Distance

FHSS spread spectrum algorithm and 67-channel pseudo-random frequency hopping make excellent anti-interference performance, ensure excellent anti-interference performance, perfect for multiplayer complete synchronously.

The actual control distance of R16SM is 3000 meters of air.

Real-time Built-In Telemetry

The receiver features a built-in data transmission function, allowing for the transmission of rich information without the need for external sensors.

In addition to real-time transmission of the RSSI value and model battery voltage, the OSD information such as latitude, longitude, speed, heading, the number of GPS satellites received, distance, PITC, ROLL, YAW, battery voltage, current, capacity, flight mode will be displayed on the transmitter screen when the R16SM is connected to the flight control and GPS.

*Attention: At the SBUS signal mode, only latitude, longitude, and battery voltage information will be telemetry, so the CRSF signal mode is suggested.

CRSF Signal Working Mode

CRSF and SBUS Signal-supported

CRSF signal working mode: When the blue LED of the R16SM is always on, the receiver is connected or welded to the TELEM1/TELEM2 port of the flight controller.

SBUS signal working mode: When the red LED of the R16SM is always on, the receiver is connected or welded to the RC IN and the TELEM1/TELEM2 port of the flight controller.

R16SM users can select CRSF or SBUS signal output mode according to their needs. And combine with the flight control to realize long-distance nesting of baitboat, fun FPV competitions for racing model cars, or long-distance voyages of fixed-wing aircraft.

SBUS Signal Working Mode

3-12V Wide Voltage Input

R16SM, with 16 channels output and 3V to 12V input voltage, is compatible with all flight controllers on the market.

R16SM Receiver

Flight Controller

Voice Broadcast Customization

When working with the RadioLink 16-channel remote control T16D, it can broadcast the current flight mode, signal strength, power battery voltage, and other information in real time.

And the voice broadcast content and voice broadcast format can be customized, so you can get the required information in real time during long-distance voyages and racing, and return home in a timely and safe manner!

Multiple Transmitter Compatible

R16SM is compatible with RadioLink T-series aircraft transmitters and all the surface transmitters.

T-series aircraft transmitters: 16 fully-proportional channels transmitter T16D, 12 fully-proportional channels transmitter T12D,

8 channels transmitter T8FB(BT), T8S(BT), T8FB(OTG), and T8S(OTG).

All the surface transmitters: 8 channels transmitter RC8X, 7 channels transmitter RC6GS V3, 5 channels transmitter RC4GS V3,

6 channels transmitter RC6GS V2, RC6GS, and 4 channels transmitter RC4GS V2, RC4GS.

Old Version(out of production) Transmitters

R16F Packing List
